Ball lenses can be used to improve signal coupling between optical fibre transmitters and detectors. Ball lenses are also used in endoscopy and barcode scanning. Ball lenses feature a short rear focal length, which minimizes the distance required from the ball lens to the optical fibre.
| DIAMETER TOLERANCE | ± 0.005mm |
| SPHERICITY | ± 0.003mm |
| SURFACE QUALITY | 60/40 |
If you have any questions or need advice on this product please get in touch.
sales@galvoptics.co.uk +44 (0) 1268 728 077| Part No. | Description | Diameter | Thickness | Focal Length | Unit Price | Quantity | |||
|---|---|---|---|---|---|---|---|---|---|
| L61-001 | BK7 BALL LENS | 1 | 1 | 0.73 | £24.00 |
|
|||
| L61-002 | BK7 BALL LENS | 2 | 2 | 1.47 | £19.00 |
|
|||
| L61-003 | BK7 BALL LENS | 3 | 3 | 2.2 | £19.00 |
|
|||
| L61-004 | BK7 BALL LENS | 4 | 4 | 2.93 | £21.00 |
|
|||
| L61-005 | BK7 BALL LENS | 5 | 5 | 3.67 | £21.00 |
|
|||
| L61-006 | BK7 BALL LENS | 6 | 6 | 4.4 | £24.00 |
|
|||
| L61-007 | BK7 BALL LENS | 7 | 7 | 5.15 | £24.00 |
|
|||
| L61-008 | BK7 BALL LENS | 8 | 8 | 5.87 | £24.00 |
|
|||
| L61-009 | BK7 BALL LENS | 9 | 9 | 6.6 | £29.00 |
|
|||
| L61-010 | BK7 BALL LENS | 10 | 10 | 7.34 | £32.00 |
|
